Axial Variable Displacement Piston Pump For Agricultural Machinery
Product Description:
To meet the needs of the agricultural sector, our company has
designed and developed a new generation of hydraulic products-
agricultural hydraulic variable displacement piston pumps. These
pumps are well-known for their compact size, flexibility and
variable displacement features, making them suitable for various
types of agricultural machinery, such as combine harvesters, forage
harvesters, tractors and other machineries.
Not only do they provide power drives for different functions such
as harvesting, conveying, loading and unloading, they also offer
superior performance, safety and high efficiency in the
agricultural field. The pumps are able to operate under different
pressure and flow conditions, adapt to different load requirements
and reduce energy consumption.
Moreover, these hydraulic piston pumps are designed for easy
installation, maintenance and control, helping to guarantee their
high-quality and reliable performance in agricultural applications.
Features:
Main Features of Axial Variable Displacement Piston Pump
For effective hydrostatic transmissions, this axial variable
displacement piston pump has a swash plate structure that aids in
its efficient performance helmed by closed-loop circuit.The pump is
capable of having a manual servo and hydraulic variable control. It
also comprises of a charging oil pump with a fixed displacement
motor and an integrated valve.
Technical Parameters:
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 |
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed
(Full load condition) | r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 |
| Min continuous working speed | r/min | 500 |
| Pressure | Rated working pressure | Mpa | 35 |
| Max working pressure (transient) | Mpa | 42 |
| Continuous working pressure | Mpa | 30 |
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 |
| Torque | Continuous output torque
(Under continuous working pressure) | Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 |
| Temperature | Allowable shell temperature | ℃ | 80 |
| Max working temperature of oil tank | ℃ | 70 |
| Weight | HPV series hydraulic pump
hydraulic oil emptying | kg | 45 | 46 | 63 | 64 | 82 | 88 |
HMF series hydraulic motor
hydraulic oil emptying | kg | 30 | 30 | 36 | 36 | 36 | 38 |
Applications:
As science and technology advance, agricultural hydraulics are
becoming increasingly commonplace. Our hydraulic pumps and motors
facilitate hydraulic farming, leading to more efficient farming
processes. These are designed to be used for a variety of farming
equipment, such as combine harvesters, tractors, sprayers, track
loaders, and forage harvesters.
These hydraulicpowered farming machines are easy to use and require
minimal resources. Unsurprisingly, they are becoming increasingly
popular amongst farmers and agricultural workers.
Laborious and cumbersome farming procedures are being made much
simpler due to the presence of this effective and accessible
technology. As a result, agricutural productivity is continually
improved.
Support and Services:
Agricultural Hydraulic Pumps Technical Support and Service
We provide technical support and service for agricultural hydraulic
pumps. Our knowledgeable technicians are available to answer your
questions and assist you in selecting the right pump for your
application. We are available to provide installation and repair
service for your hydraulic pump as well.
Our technical support staff can help you troubleshoot any problems
you may be having with your hydraulic pump. We can also assist you
in selecting the right models for your agricultural hydraulic pump.
We can provide you with detailed product information and help you
with any installation or repair.
Our service technicians are well-trained and experienced in
hydraulic pump repair and maintenance. We will inspect your
hydraulic pump and make any necessary repairs or adjustments to
ensure it is operating correctly. We can also provide you with
advice on how to maintain and extend the life of your hydraulic
pump.
We are dedicated to providing you with the best possible technical
support and service for your agricultural hydraulic pump. If you
have any questions or concerns, please do not hesitate to contact
us.
FAQ:
Q: What is the brand name of the Agricultural Hydraulic Pumps?
A: The brand name of the Agricultural Hydraulic Pumps is HIGHLAND.
Q: What is the model number of the Agricultural Hydraulic Pumps?
A: The model number of the Agricultural Hydraulic Pumps is HPV110.
Q: Where is the origin of the Agricultural Hydraulic Pumps?
A: The origin of the Agricultural Hydraulic Pumps is CHINA DEZHOU.
Q: What is the certification of the Agricultural Hydraulic Pumps?
A: The certification of the Agricultural Hydraulic Pumps is PATENT
and ISO CERTIFICATE.
Q: What is the minimum order quantity of the Agricultural Hydraulic
Pumps?
A: The minimum order quantity of the Agricultural Hydraulic Pumps
is 5 sets.
